Ral Color PPGL PE SMP PVDF Metal Building Material Color Coated Coils Bright Matt High Light
Surface Filming Dx52D PPGI
- Place of Origin:Tianjin, China
- Standard:AiSi, ASTM, bs, DIN, GB, JIS
- Grade:SGCC, SPCC, DC01
- Model Number:DX51D
- Type:Steel Coil, PPGI
- Technique:Cold Rolled
- Surface Treatment:galvanized, aluminum, colour coated
- Application:Structural use ,roofing, commercial use, household
- Special Use:High-strength Steel Plate
- Width:750-1250mm
- Length:500-6000mm as you required
- Tolerance:standard
- Thickness:0.13mm to 1.5mm
- width:700mm to 1250mm
- zinc coating:Z35-Z275 or AZ35-AZ180
Application areas:
Construction industry: production of exterior and interior products such as metal tiles, corrugated sheets, sandwich panels, profiles, metal ceilings, skirting boards, decorative panels in heated and non-heated rooms, lifts, window and door shutters, shelving, etc.
Automotive industry: production of interior and exterior body parts (doors, boots, oil filters, instrument panels, windscreen wipers, etc.)
Manufacture of household appliances, furniture and consumer goods: metal furniture, lighting fixtures, shelves, radiators, doors, boots, etc.
PPGI is widely used in column and beam construction, civil engineering and decoration. Colored corrugated sheet is tough, useful and aesthetically pleasing. PPGI guarantees that buildings, automobiles and household appliances will retain their shine for years to come.
Steel Grade:
EN10346-DX51D/ DX52D/ DX53D, S250GD/280GD/350GD/550GD, ASTM A527M, CS-B, SS255-SS550
Paint Brand:
Valspar/ Beckers
Loading Port:
Qingdao/Tianjin Port
| Thickness: | 0.25--1.2 mm |
| Width: | 600--1250 mm |
| Coil weight: | 3--12 MT or as requirements |
| Coating: | AZ30-AZ150g/m2 |
| Surface types: | 2/1 Coat the top surface of the steel sheet twice, coat the bottom surface once, and bake the sheet twice.Front side paint |
| thickness: 15-25μm (bottome paint + top paint) Front side paint thickness: 15-25μm (bottome paint + top paint) Back side paint |
| thickness: 5-10μm |
| Surface Treatment: | Normal Coated, RAL system, as customers' requirement |
| Standard: | ASTM,BS,EN,JIS |
| Grade: | CQ, G550, Grade33, Grade37, Grade40 |
| Paint type: | PE | Good adhesion, durability, chemical resistance. Service life is 7-10 years |
| SMP | Excellent hardness, heat resistance. It has the good durability and powder resistance, giossy resistance. Service life is 10-12 years |
| HDP | Better UV resistance, high durability , the mainly performance between PE and PVDF coating. Service life is 10-1S years |
| PVDF | Best formatlity and color retention, excellent outdoor durbty, dust resistance, solvent resistance Service life is 20-25 years |
| Payment: | T/T ,L/C at sight |
