self-cleaning Beckers Blue 0.50-1.0mm 1200mm Z225 PPGI Pre-painted color coating steel DX51D for roofing Wall Panel
Product details:
The self-cleaning PPGI/PPGL coils with special paint has excellent anti-staining properties, which can resist the penetration of pollutants to the coating, and also has a good self-cleaning property by rain So it can reduce the pollution of industrial emissions,auto exhaust gas, fumes,dust ,as well as the cost of maintenance to the building.
Color coated steel is coated with paint using the roller coating method, and the product is made by conversion treatment baking and cooling. The substrates of color coated sheet include cold rolled substrate, hot-dip galvanized substrate and electro-galvanized substrate, aluminized zinc substrate. Color coated panel topcoat coating types can be divided into polyester, silicone modified polyester, partial polyfluoroethylene, high weathering polyester and so on. Production process has been developed from a coating and baking for two coating and baking.
There is also a three-coating and three-baking process. Color coated plate has a variety of colors, such as white gray, aquamarine, orange, sky blue, scarlet, brick red, ivory, cerulean blue and so on. The surface state of color coated plate can be divided into ordinary coated plate, embossed plate and printed plate. The market use of color coated sheet is mainly divided into construction, home appliances and transportation.
Color coated steel plate has beautiful appearance, light weight, good corrosion resistance, and can be directly processed, providing a new type of steel instead of wood, efficient construction, energy saving and anti-pollution advantages.
1, color coated sheet is widely used, with no pollution, weather resistance, corrosion resistance, high processability. Color coated sheet is generally widely used in industry, construction, home appliances, packaging, machinery and other fields. Involving processing, transportation, interior decoration, medical and automotive industries.
2, color coated sheet in home appliances in the use of 31%, while the use of 63% in construction, is indispensable to the construction industry, and other aspects of the use of less, about 6%%, galvanized steel as the substrate of the coated sheet has a protective and isolation function, not only to prevent the steel plate rust, the service life of 50% longer than before, and has a stronger protective effect.
Application areas:
In the construction sector: manufacture of exterior and interior products such as metal shingles, corrugated sheets, sandwich panels, profiles, metal ceilings, skirting boards, decorative panels inside heated and unheated premises, elevators, doors, window shutters, shelves, etc.
in the automotive industry: for the manufacture of exterior and interior body parts (car doors, car shoes, oil filters, dashboards, windscreen wipers, etc.).
In the manufacture of household appliances, furniture and consumer goods: metal furniture, lighting equipment, shelving, radiators, car doors, car shoes, etc.
PPGI is widely used in column and beam construction, civil engineering and decoration. Colored corrugated sheet is tough, useful and aesthetically pleasing. PPGL guarantees that buildings, automobiles and household appliances will retain their shine for years to come.
Steel Grade:
EN10346-DX51D/ DX52D/ DX53D, S250GD/280GD/350GD/550GD, ASTM A527M, CS-B, SS255-SS550
Paint Brand:
Valspar/ Beckers
Loading Port:
Qingdao/Tianjin Port
| Thickness | GI 0.20mm~1.70mm GL 0.20mm~3.0mm |
| Width | 600mm~1500mm |
| Zink-Coating | Z40~Z275g/㎡ AZ30~AZ200g/㎡ |
| Paint Structure | 2/1, 2/2, 3/2, 3/3 |
| Paint Coating | Top side 15μm~55μm Back side 5μm~30μm |
| Structural Grades | C | Mn | P | S | Al | Si | Cu | Ni | Cr | Mo | V | Cb | Ti | N |
| 30,33,36,40 | 0.25 | 0.9 | 0.035 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| 36T2,45-80 | 0.25 | 1.35 | 0.035 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| 45T2 | .02- 0.08 | .30- 1.0 | .03- .07 | 0.025 | .02- .08 | 0.6 | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | .01- .03 |
| HSLA Grades | C | Mn | P | S | Al | Si | Cu | Ni | Cr | Mo | V | Cb | Ti | N |
| 45C1 | 0.22 | 1.35 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 45C2 | 0.15 | 1.35 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 50C1 | 0.23 | 1.35 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 50C2 & 55C2 | 0.15 | 1.35 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 55C1 | 0.25 | 1.35 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 60C1 & 65C1 | 0.26 | 1.5 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 60C2 & 65C2 | 0.15 | 1.5 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.005 | 0.005 | 0.005 | |
| 70C1 | 0.26 | 1.65 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.16 | 0.005 | 0.005 | 0.005 | |
| 70C2 | 0.15 | 1.65 | 0.04 | 0.04 | | | 0.2 | 0.2 | 0.15 | 0.16 | 0.005 | 0.005 | 0.005 | |
| Common Grades | C | Mn | P | S | Al | Si | Cu | Ni | Cr | Mo | V | Cb | Ti | N |
| CSA | 0.1 | 0.6 | 0.03 | 0.035 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| CSB | 0.02-.15 | 0.6 | 0.03 | 0.035 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| CSC | 0.08 | 0.6 | 0.1 | 0.035 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| BH | 0.012 | 1.5 | 0.12 | 0.03 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| FSA | 0.1 | 0.5 | 0.02 | 0.035 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| FSB | 0.02-.15 | 0.5 | 0.02 | 0.03 | | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| DDS | 0.06 | 0.5 | 0.02 | 0.025 | .01 | | 0.2 | 0.2 | 0.15 | 0.06 | 0.008 | 0.008 | 0.025 | |
| EDDS | 0.02 | 0.4 | 0.02 | 0.02 | .01* | | 0.2 | 0.2 | 0.15 | 0.06 | 0.1 | 0.1 | 0.15 | |
